CLAHE

Overview

The CLAHE sample demonstrates Contrast Limited Adaptive Histogram Equalization using CV-CUDA’s GPU-accelerated cvcuda.clahe operator. CLAHE improves local contrast by equalizing the histogram of small contextual tiles independently, then clipping the amplification to a user-supplied limit to suppress noise amplification. The result is a perceptually clearer image without the over-saturation that can occur with global histogram equalization.

Because cvcuda.clahe requires a single-channel (grayscale) U8 tensor, the sample first converts the RGB input to grayscale, applies CLAHE, and then replicates the enhanced grayscale channel across R, G, and B for a viewable output image.

Usage

Basic Usage

Apply CLAHE to an image (default clip_limit=2.0, tile_grid_size=(8, 8)):

python3 clahe.py -i input.jpg

Custom Example

Specify a custom input and output path:

python3 clahe.py -i input.jpg -o cat_clahe.jpg

Command-Line Arguments

Argument

Short Form

Default

Description

--input

-i


Input image file path

--output

-o

cvcuda/.cache/cat_clahe.jpg

Output image file path

Implementation

CLAHE Operator

# CLAHE requires a single-channel (grayscale) U8 tensor.
# Convert the RGB input to grayscale using cvtcolor, producing HWC with C=1.
nhwc_image: cvcuda.Tensor = cvcuda.stack([input_image])
gray_nhwc: cvcuda.Tensor = cvcuda.cvtcolor(
    nhwc_image, cvcuda.ColorConversion.RGB2GRAY
)

Key points:

  1. Grayscale requirement: cvcuda.clahe only accepts single-channel U8 tensors; RGB inputs must first be converted with cvcuda.cvtcolor(src, cvcuda.ColorConversion.RGB2GRAY).

  2. clip_limit: Values above 1.0 enable contrast limiting; the default of 2.0 provides moderate enhancement while suppressing noise. Setting it to 0.0 raises an exception.

  3. tile_grid_size: The tuple (cols, rows) of contextual tiles; each tile must be at least 1×1. Larger grids produce more localised adaptation at the cost of extra computation.

  4. Stream support: An optional stream keyword enables asynchronous GPU execution; call stream.sync() before reading results back to the host.

  5. Batch support: The operator accepts both HWC (single image) and NHWC (batch) tensors as well as variable-shape image batches (ImageBatchVarShape).

Expected Output

The output shows the grayscale-enhanced image saved as a three-channel (RGB) JPEG for viewer compatibility:

../../_images/tabby_tiger_cat.jpg

Original Input Image
../../_images/cat_clahe.jpg

Output: CLAHE-enhanced grayscale (replicated to RGB)

CV-CUDA Operators Used

Operator

Purpose

cvcuda.clahe()

Contrast Limited Adaptive Histogram Equalization on a grayscale tensor

cvcuda.cvtcolor()

Convert RGB input image to single-channel grayscale before CLAHE

cvcuda.stack()

Stack the HWC input tensor into an NHWC batch for cvtcolor

Common Utilities Used

  • read_image() - Load image as CV-CUDA tensor

  • write_image() - Save CLAHE-enhanced image

  • cuda_memcpy_d2h - Download CLAHE result to host for grayscale-to-RGB replication

  • cuda_memcpy_h2d - Upload the replicated RGB array back to a CVCUDA tensor
