Joint Bilateral Filter

Overview

The Joint Bilateral Filter sample demonstrates edge-preserving image smoothing using CV-CUDA’s GPU-accelerated joint bilateral filter operator. Unlike the standard bilateral filter, the joint (cross) variant uses a separate guidance image to steer the range kernel — edges detected in the guidance image are preserved in the filtered output, making it well-suited for noise reduction while retaining sharp structural boundaries.

Usage

Basic Usage

Apply joint bilateral filtering to an image using the default input:

python3 joint_bilateral_filter.py -i input.jpg

Custom Output

Specify a custom output path:

python3 joint_bilateral_filter.py -i input.jpg -o cat_joint_bilateral_filter.jpg

Command-Line Arguments

Argument

Short Form

Default

Description

--input

-i


Input image file path

--output

-o

cvcuda/.cache/cat_joint_bilateral_filter.jpg

Output image file path

Implementation

Joint Bilateral Filter

# The joint bilateral filter smooths `src` guided by `srcColor`.
# Using a grayscale-converted version of the image as the guidance signal
# keeps edges defined by luminance sharp while smoothing color noise.
# We batch the HWC tensor to NHWC so cvtcolor (which requires a batch dim) works.
nhwc_image: cvcuda.Tensor = input_image.reshape((1, *input_image.shape), "NHWC")
guidance_image: cvcuda.Tensor = cvcuda.cvtcolor(
    nhwc_image, cvcuda.ColorConversion.RGB2GRAY
)
# cvtcolor produces a 1-channel NHWC tensor; replicate to 3 channels so it
# matches the source tensor's channel count, which joint_bilateral_filter requires.
guidance_3ch: cvcuda.Tensor = cvcuda.cvtcolor(
    guidance_image, cvcuda.ColorConversion.GRAY2RGB
)

Key points:

  1. Guidance image: A grayscale-derived image is used as the guidance signal so that luminance edges govern which pixels are blended — colour-channel noise is reduced without crossing structural boundaries.

  2. Channel matching: srcColor must have the same spatial size and channel count as src; the grayscale result is converted back to 3-channel RGB before being passed as guidance.

  3. diameter: Controls the neighbourhood size; larger values consider farther pixels but increase cost quadratically.

  4. sigma_color / sigma_space: Larger values produce stronger smoothing; sigma_color governs how different colours can still be blended, sigma_space governs spatial reach.

  5. Batch dimension: The HWC tensor read from disk is reshaped to NHWC for cvtcolor and the filter call, then reshaped back to HWC before writing the output.

Expected Output

The output is a smoothed version of the input with fine texture noise reduced while prominent edges — fur boundaries, whiskers — remain sharp because the luminance guidance image keeps them intact.

../../_images/tabby_tiger_cat.jpg

Original Input Image
../../_images/cat_joint_bilateral_filter.jpg

Output: Joint Bilateral Filtered

CV-CUDA Operators Used

Operator

Purpose

cvcuda.joint_bilateral_filter()

Edge-preserving smoothing guided by a separate reference image

cvcuda.cvtcolor()

Convert RGB to grayscale (and back) to build the guidance tensor
