Composite

Overview

The Composite sample demonstrates GPU-accelerated image compositing with CV-CUDA. It blends a foreground image (tabby cat) over a background image (Weimaraner dog) using a single-channel alpha mask. A filled circle in the centre of the frame keeps the cat visible while the dog shows through outside the circle, making the blend immediately obvious in the output image.

Usage

Basic Usage

Composite the default cat foreground over the Weimaraner background:

python3 composite.py -i input.jpg

Custom Input

Supply your own foreground image and redirect the output:

python3 composite.py -i image.jpg -o cat_composite.jpg

Command-Line Arguments

Argument

Short Form

Default

Description

--input

-i


Foreground input image file path

--output

-o

cvcuda/.cache/cat_composite.jpg

Output composited image file path

Implementation

Composite Operation

h, w, c = fg_image.shape  # HWC layout from read_image

# Resize the background to match the foreground's spatial dimensions so
# cvcuda.composite can pair them element-wise on the GPU.
bg_image: cvcuda.Tensor = cvcuda.resize(bg_raw, (h, w, c))

# Build the foreground mask on the CPU using NumPy, then upload it.
# The mask is single-channel uint8: 255 = keep foreground, 0 = show background.
# A circular region in the centre of the frame exposes the cat; the rest
# shows the Weimaraner, giving a clear visual demonstration of blending.
mask_np = np.zeros((h, w, 1), dtype=np.uint8)
cy, cx = h // 2, w // 2
radius = min(h, w) // 3
# Vectorised distance computation avoids a slow Python loop.
ys, xs = np.ogrid[:h, :w]
inside_circle = (xs - cx) ** 2 + (ys - cy) ** 2 <= radius**2
mask_np[inside_circle, 0] = 255

# Allocate a GPU tensor for the mask and copy the host data across.
# upload_tensor honours the mask tensor's row pitch (a single-channel mask
# is padded to an alignment boundary); a packed copy would shear the mask.
mask_tensor: cvcuda.Tensor = cvcuda.Tensor((h, w, 1), dtype=np.uint8, layout="HWC")
upload_tensor(mask_np, mask_tensor)

Key points:

  1. Mask shape: The foreground mask must be single-channel (HWC with C=1), uint8.

  2. Spatial alignment: Foreground, background, and mask must share the same (H, W) dimensions; the background is resized to match the foreground before compositing.

  3. outchannels parameter: Pass 3 for an RGB output tensor or 4 for RGBA.

  4. Mask semantics: Pixel values > 0 select the foreground; 0 selects the background — effectively a hard binary blend.

  5. GPU upload: The mask is constructed on the CPU with NumPy then transferred to the GPU via cuda_memcpy_h2d before the operator call.

Expected Output

The composited image shows the cat inside a circular region with the Weimaraner dog visible outside it:

../../_images/tabby_tiger_cat.jpg

Original Input Image (foreground)
../../_images/cat_composite.jpg

Output: Cat composited over Weimaraner

CV-CUDA Operators Used

Operator

Purpose

cvcuda.composite()

Blend foreground and background images using an alpha mask

cvcuda.resize()

Resize the background to match foreground spatial dimensions
